D1N D-Frame Single Crank Press Machine

Quantity:
  • D1N80-260 Ton

  • goawnin

·Straight side frame designed virtually eliminates angular deflection, suitable for precise continuous mold processing.

·Save the mold maintenance costs.

·Super rigid frame.

·High driving torque clutch & brake.

·No pollution, low noise, according with environmental protection requirement.

·User friendly , multi-function control system   for easy integration of auxiliary equipment and automation.


Model

D1N-80

D1N-110

D1N-160

D1N-200

D1N-260

 V

H

V

H

V

H

V

H

V

H

Capacity

Ton

80

110

160

200

260

Rated tonnage point

mm

  4

2

6

3

6

3

6

3

7

3.5

Stroke

mm

  150

70

180

80

200

90

200

100

250

150

Die height

mm

  340

380

360

410

460

515

460

510

500

550

Stroke per minute variable

s.p.m

  35-80

80-120

30-60

60-90

20-50

40-70

20-50

50-70

20-40

20-50

Slide adjustment

mm

80

80

100

110

120

Slide Area

mm

560x420x70

650x470x80

700x550x90

850x630x90

950x700x100

Bolster area

mm

930x550x90

1090x600x110

1190x880x140

1400x820x160

1530x840x180

Main motor

kw.p

7.5x4

11x4

15x4

18.5x4

22x4

Slide adjust device

HP

Electrial driving

Air presses

kg/cm²

6

6

6

6

6

Presses dimendion

mm

1300x1890x3000

1420x1985x3200

1600x2200x3500

1750x2500x3900

2780x1850x4470

Presses precision



GB(JIS)1class

GB(JIS)1class

GB(JIS)1class

GB(JIS)1class

GB(JIS)1class

Die cushion capacity

Ton

3.6

6.3

10

14

14

Die cushion Stroke

mm

70

80

80

100

100

Die cushion effective area

mm²

450x310

500x350

650x420

710x480

810x480


Standard accessories

Optional accessories

Inverter



Touch pad



Preset counter

Electrical automatic lubrication system

Electrical cam

pneumatic die cushion device

Hydraulic over-load protectort

Foot switch

Electric Silde adjust device

Quick die change device(die lifter, clamp and die arm sepjes)

Electric Die height indicatot

Slide knock-out device

Balance device

Die room light

Crank angle indicator

Photo-electronic safety device

Electric stroke counter

Feeder

Air source receptacle

Uncoiler

Against over-run safety device

Leveler

Misfeed detection consent

Mechanism hand

Power socket



Maintenance tool box



Operation Manual



Anti vibration press mount
